Loud and clear.
To record great-sounding music, you need outstanding preamps and digital converters. And to hear what you’re doing, you need a headphone amp that keeps up with the rest of the design. The AudioBox iTwo audio interface delivers it all! We’re famous for our award-winning microphone preamplifiers, and we’ve equipped the AudioBox iTwo with a sweet-sounding mic preamp that will capture your voice in all its glory. Clean, clear, 24-bit, 96 kHz digital converters and an ultra-loud, crystal-clear headphone output ensure you hear every detail.
Features
Core Technology
- Bus-powered USB 2.0/iPad® audio interface
- 24-bit resolution; 44.1, 48, 88.2, and 96 kHz sampling rate
Inputs and Outputs
- 2 microphone inputs with low-noise, high-headroom, Class A mic preamplifiers and +48V phantom power
- 2 switchable line/instrument inputs
- 2 balanced ¼-inch TRS main line-level outputs
- 1x1 MIDI In/Out
- Stereo headphone output with independent level control
Controls
- Zero-latency monitoring via internal analog mixer (variable mix via Mix knob)
- Large main volume knob
- Signal present and clipping LEDs
Integrated Software
- Studio One® Artist DAW software (macOS®/Windows®) and 6+ GB of third-party resources
- Transfer files wirelessly from Capture for iPad to Studio One
- Compatible with almost all recording software for Mac, Windows, and iPad
- Studio Magic Software Suite included
- Ableton® Live Lite included
Computer system requirements:
Below are the minimum computer-system requirements for AudioBox iTwo.
macOS®
- macOS version 10.13 or later
- 200 MB storage space and 4 GB RAM for Universal Control (required for firmware updates)
- Available USB port
Windows®
- Windows 10 or later (64-Bit Only)
- 200 MB storage space and 4 GB RAM for Universal Control (required for firmware updates and low-latency ASIO support)
- Available USB port
Apple iPad
- iPad® Pro, iPad Air, iPad mini with Retina display, iPad (4th generation)
- iOS® 10.0.3 or higher
Microphone Preamp |
|
|---|---|
| Type | XLR female, balanced |
| Frequency Response (±3.0 dB) | 20 Hz to 20 kHz |
| Input Impedance (Balanced) | 1,200Ω |
| THD+N (unwtd, 1 kHz @ +4 dBu Output, Unity Gain) | < 0.008% |
| S/N Ratio (Unity Gain, Ref. = +4 dBu, 20 Hz to 22 kHz) | > 95 dB |
| Common Mode Rejection Ratio (1 kHz, 52 dB Gain) | — |
| Gain Control Range (± 1 dB) | 0 dB to 52 dB |
| Max Input Level (Unity Gain, 1 kHz @ 0.5% THD+N) | +10 dBu |
| Phantom Power (±2 VDC) | +48 VDC |
Line Input |
|
|---|---|
| Type | ¼" TRS female, balanced |
| Input Impedance | 10 kΩ |
Instrument Input |
|
|---|---|
| Type | ¼" TS female, unbalanced |
| Input Impedance | 1 MΩ |
Line Outputs |
|
|---|---|
| Type | ¼" TRS female, balanced |
| Output Impedance | 51Ω |
Headphone Output |
|
|---|---|
| Type | ¼" TRS active stereo |
| Maximum Output | 60 mW/ch. @ 60Ω Load |
| Frequency Response (±1.0 dB) | 20 Hz - 30 kHz |
MIDI I/O |
|
|---|---|
| Type | Dual 5-pin female DIN |
Digital Audio |
|
|---|---|
| ADC Dynamic Range (A-wtd, 48 kHz Sample Rate) | 105 dB |
| DAC Dynamic Range (A-wtd, 48 kHz Sample Rate) | 105 dB |
| Bit Depth | 24 |
| Reference Level for 0 dBFS | +10 dBu |
| Supported Sample Rates (kHz) | 44.1, 48, 88.2, 96 |
| Power | USB bus-powered |
Physical |
|
|---|---|
| Height | 1.71” (43.5 mm) |
| Depth | 5.31" (135 mm) |
| Width | 7.56” (192 mm) |
| Weight | 1.35 lbs (0.62 kg) |
