PRODUCT HARDWARE SPECIFICATIONS
- 25 Minikeys
- 1 x Touch Strip for Pitch-bench with centre zero
- 1 x Touch Strip for Modulation
- 8 x Knobs
- 16 RGB Backlit, Velocity Sensitive Pads
- Transpose Buttons
- Octave Up/Down Buttons (with Preset function as shift)
- Play and Record Buttons
- Arp, Fixed Chord Buttons
- Stop/Solo/Mute Button
- Scene Launch Button
- 3.5mm TRS MIDI Type A jack socket for MIDI Out (MIDI din break-out cables NOT included)
- USB Socket
- Kensington MiniSaver Slot
- Midi Channel Selection
- Capture MIDI function
- Tracks function
- Scene Down function
- Scene Up function
SOFTWARE COMPATABILITY
- Ableton Live Lite is included
- Logic script, Reason script; all other DAWs through HUI i.e. Protools, Reaper, Studio One.
POWER REQUIREMENTS
- USB bus powered
- Power supply not included
PRODUCT DIMENSIONS
- 330mm length x 172mm depth x 31mm (40mm including knob-caps) height
